RS 380 DC motor is a small permanent magnet DC motor. 3 pole armature, also can be 5 pole. The output shaft riveted gear, so can assembly with gear box. This brush DC 380 motor uses Pure Copper Wire, Not Aluminium Wire, so it is more reliable and long lifetime. MGLORY DC motor China can provide custom brushed DC motor services with your own design.
| Model Number | RS380 |
| Construction | Permanent Magnet |
| Commutation | Carbon Brush |
| Material of the Housing | SECD |
| Motor Housing Shape | Round |
| Motor Cover | Iron |
| Motor Diameter | 27.8mm |
| Motor Length | 37.8mm |
| Shaft Diameter | 2.3mm |
| Shaft Material | Carbon Steel |
| Bearing | Oil Bearing |
| Power | DC |
| Rotation | CCW/CW |
| Cooling Fan | No |
| Motor Weight | 80g Around |
Custom DC motors are available at MGLORY.
| Model | Voltage | No Load | At Maximum Efficiency | Stall | ||||||
| Speed | Current | Speed | Current | Torque | Output | EFF | Torque | Current | ||
| rpm | A | rpm | A | mN.m | W | % | mN.m | A | ||
| RS380- 14280 | 12.0 | 4300 | 0.07 | 3400 | 0.23 | 4.1 | 1.5 | 57 | 23.8 | 1.0 |
| RS380- 5015 | 4.0 | 25000 | 2.10 | 19900 | 10.77 | 13.2 | 27.7 | 65 | 61.5 | 41.9 |
| Note: It's only typical technical data for reference. Special requirements of DC motor wholesale can be customized, please refer to chart below. | ||||||||||
| Voltage Range | 3V to 36V |
| Speed Range | 2000rpm to 25000rpm |
| Power Range | 0.5W to 43W |
| Torque Range | 3mN.m to 20mN.m |
| Stall Torque Range | 40mN.m to 200mN.m |
